Product Description



Ningbo Haitian Magnets Co.,Ltd. is a round magnetic chuck, radial magnetic chuck manufacturer produces magnetic tools magnetic clamp and magnetic assembles. We can design many magnetism clamps, supply magnetism system designing, subject designing and consultation of magnetism materials. Company’s professional knowledge can offer the best help and service to the backward customers. The custom round magnetic chucks, radial magnetic chucks products are used for electrical machine, mechanisms, mould, machining, etc industry field and many mechanisms. They are also used for family, office, marketed.

RMC

round magnetic chuck

With fine parallel pole pitch P = 2. mm，Pole pitch: steel 1.5 mm, brass 0.5 mm
Use:
Clamping of small and thin
to medium-sized workpieces.
Features:
Extremely low height due to use of neodymiumiron-
boron magnets. Pole pitch P = 2.mm.
Nominal holding force: 80 N/cm2
Magnetic field height: 8 mm
Pole plate wearing limit: 5 mm

RMC
radial magnetic chuck


Dimensions(mm) Weight
in kg
Model A  B+0.5 -2  C  D  E F G
RMC100  100 43 65 2 85 3 x M8  14 2
RMC130  130 43 100 2 115 3 x M8  14 4.5
RMC160  160 43 125 2 140 4 x M8  14 6.5
RMC200  200 43 160 2 180 4 x M8  14 10
RMC250  250 43 200 2 224 4 x M10  14 15
RMC300  300 45 230 3 260 4 x M10  14 25
RMC320  320 45 230 3 260 4 x M10  14 32
RMC350  350 56 300 4 330 4 x M10  16 43
RMC400  400 56 300 4 350 6 x M10  16 52
